Here is the description for SAFETY. Note there are features here which are still not available on other computing platforms, though some additions designed in (see the code) for things like access frequency checking or inheritance of security attributes on creation of files, or similar controls on network access, are not described here. There was never much demand for Safety on VMS owing to the OS' unpopularity and probably due to the difficulty of getting people to accept functions of this kind from a third party tiny shop, rather than the OS vendor. The author moved on to other things and did not believe in attempting to reimplement the whole scheme for Windows and had not sufficient interest to do it for Linux, where at least the code is open.

Software Product Description

Safety V1.4

   Comprehensive Data Safety for your VMS systems.

     from General Cybernetic Enterprises

  Executive Summary:

There are many perils your data faces, and loss of data can cost time, money, and jobs. Intruders, disgruntled insiders, or
 hidden flaws in installed software can destroy records. What is
 more, mistaken losses occur constantly.

Safety protects your system and your critical data in three ways:

1. A comprehensive security system adds extra checks for access
   to VMS files so that access by intruders or by people in
   non-job-required ways can be regulated or prevented. This allows
   your business - critical data to finally be protected against
   misuse, tampering, or abuse. Access from programs doing
   background dirty work (viruses, Trojans, worms, and the like, or
   even programs with security holes which can be exploited
   remotely (like Java browsers)) can also be blocked without
   damaging normal use. This active protection works three ways: by
   checking integrity    of your files against tampering, by
   preventing of  untrusted images from  gaining privilege, and by
   regulating what other parts of the system an image may access.

   2. A deletion protection system provides a way to undelete files
   which were deleted by mistake and to optionally copy deleted
   files to backup facilities before removal. Unlike all other VMS
   "undelete" programs on the market, this facility does not rely
   on finding the disk storage that contained the file and
   reclaiming it before it is overwritten. Rather, it changes the
   semantics of the file system delete to use a "wastebasket"
   system and captures the file intact. Thus, this system works
   reliably. No others do. This facility is also useful where you
   have a requirement to keep all files of a certain set of types,
   since the backup function can be used to capture such files
   while permitting otherwise normal system function. The shelving
   or linking functions are also available for moving copies
   offline if this is desired. The  Safety protection features are
   fully integrated with the DPS subsystem, so that deletion
   protection does not involve destroying file security.

   3.  When space runs out, hasty decisions about what to keep
   online often must be made, and the risk of accidentally losing
   something important is high.   Safety protects you from running
   out of space. Space can be monitored and older items in the
   wastebasket deleted if it is becoming low, without manual
   intervention. In addition, Safety  is able to "shelve" files so
   that they are stored anywhere else desired on your system, and
   they are brought back automatically when accessed. Thus no
   manual arrangements need be made for reloading them.  Safety can
   also keep the files on secondary storage, keeping a "soft link"
   to the files at their original site so they will be accessed on
   the secondary storage instead. Also,    Safety can store files
   compressed, or can store them on secondary storage so that read
   access is done on the secondary storage, but write access causes
   the file to be copied back to its original site. Standard VMS
   utilities are used for all file movement, and moved files are
   also directly accessible in their swapped sites with standard
   VMS utilities. The VMS file system remains completely valid at
   all times.

   Safety gives you a full complement of tools  for dealing with
   space issues automatically according to your site policy. These
   facilities are safe and easily understood.  A comprehensive
   utility is provided by which you set your site policy to select
   which files are and are not eligible for automatic shelving.
   Also you are provided with screen oritented utilities for
   selecting files to shelve at any time. Access to the shelved
   files of course causes unshelving if the normal shelving-by-copy
   mode is used. Also, a simple set of rules permit locating
   shelved or softlink target files at any time, even without
   Safety running.   Safety at no time invalidates your file
   structures for normal VMS access...not even for an instant.

   In addition Safety contains functions to speed file access and
   inhibit disk fragmentation.

   The major subsystems of Safety will now be described.

   The Security Function System:
   Managing access to data critical to your business using ACL
   facilities in native VMS can be cumbersome and still is
   vulnerable to intruders or people acting in excess of their

   Want to be sure your critical records can't be accessed save at
   authorized places, times, and with the programs that are
   supposed to access them (instead of, say, COPY.EXE)?

   Want to have protection against privileged users bypasssing
   access controls?

   Want to be able to password protect individual files?

   Want to be able to invisibly hide selected files from
   unauthorized intruders?

   Have you read that attacks on machines can happen because a scripting
   browser points at a web site that damages the system (as has
   been reported in the press)? Want to be able to protect your

   The Safety security subsystem builds in facilities permitting
   all of these, and is not vulnerable to intruders who disable the
   AUDIT facility as all other commercial packages which purport to
   monitor access are.

   Description: When your business depends on critical files, or
   when you are obliged by law or contract to maintain
   confidentiality of data on your system, in most cases the
   options provided by VMS for securing this data can be cumbersome
   and far too coarse-grained.

   The problem is that certain kinds of access to data are often
   needed by people in a shop, but other access should be prevented
   and audited. Moreover, the wide system access that can come as a
   result of having system privileges often does not mean that it
   should be used to browse or disclose data stored on the system.
   A system manager will in general not, for example, have any
   valid reason to browse the customer contact file, the payroll
   database, or a contract negotiation file, save in a few cases
   where these files need to be repaired or reloaded from backups.
   Likewise, a payroll clerk may need read and write access to the
   payroll file, but not in general with the COPY utility, nor from
   a modem, nor in most cases at 4AM. Finally, a person who must
   have privileges to design a driver and test it should ordinarily
   not have the run of the file system as well.

   Given examples like these, it is easy to see that simple
   authorization of user access to files is inadequate. While it is
   possible to build systems that grant identifiers to attempt some
   extra control, these can be circumvented by privilege, and
   create very long ACLs which become impossible to administer over
   a long period as users come and go.

   What is needed is a mechanism that is secure, cannot be
   circumvented by turning on privileges, and which provides a
   simple to administer and fine grained control that lets you
   specify who can get at your critical files, with what images,
   when, from where, and with what privileges. It is also desirable
   to be able to control what privileges the images ever see, and
   to be able to check critical command files or images for
   tampering before use, so that they cannot be used as back doors
   to your system. It should be possible to demand extra
   authentication for particular files as well, and to prevent a
   malicious user from even seeing a particularly critical file
   unless he can be permitted access.

   The Safety security subsystem is a VMS add-in security package
   which provides abilities to control security problems due to
   intruders, to damage or loss by system "insiders" (users
   exceeding their authority), and to covert code (worms and
   viruses). It provides a much easier management interface to
   handle security permissions than bare VMS and provides
   facilities permitting control over even privileged file
   accesses, for cases where there are privileged users whose
   access should be limited. Unlike systems which only intercept
   the AUDIT output, EACF can and does protect against ANY file
   accesses, and can protect files against deletion by unauthorized
   people or programs in real time as well as against access.

   The Safety security subsystem offers the following capabilities:

   * Files can be  password protected individually. If a file open
   or delete is attempted for such a file and no password has been
   entered, the open or delete fails.

   * Access can be controlled by time of day. Added protections can
   be in place only some of the time, access can be denied some
   times of day, write accesses can be denied at certain times, or
   various other modalities of access can be allowed.

   * You can control  who may access a file, where  they may be (or
   may not be),  with what images  they may or may not access the
   file, and with what privileges  the file may be accessed. Thus,
   for instance, it is trivial to allow a clerk access to the
   payroll file with the payroll programs, but    not with COPY or
   BACKUP, not on dialup lines, and not if they have unexpected
   privileges. The privilege checks can be helpful where there are
   consultants working on a system who should be denied access to
   sensitive corporate information but who need privileges to
   develop programs, or in similar circumstances. You specify what
   privileges are permitted for opening the file, and a process
   with excess privileges is prevented  from access. Vital business
   data access should not always be implied by someone having
   privilege. With this system you can be sure your proprietary
   plans or data stay in house, and are available only to those
   with business reasons to need them, not to everyone needing
   system privileges for unrelated reasons. Unlike packages using
   the VMS Audit facility's output (which can be silently turned
   off by public domain code),   Safety cannot  be circumvented by
   well known means. Its controls are designed to leave evidence of
   what was done with them as well.

   * You can specify that images (programs) able to run portable code (applet
      viewing programs or programs with powerful scripting languages)
      trigger a "paranoid mode" system. When this is triggered
      (normally when the "loading" image is active), all file opens
      by the process running the triggering image are filtered by a
      script. This script can be different for different programs,
      and is site customized. The furnished sample script will
      broadcast the identity of user and of files being opened. It is
      trivial to arrange to limit this to unusual files or filesystem
      areas.  The script can also veto the open. Thus the recommended
      way to treat web browsers is to limit their file access so they
      may read system areas and a scratch area, and may write only a
      scratch area. (The script is informed whether the open is for
      read or for write.) This "low-integrity-image" mode in which
      all file opens are checked with a site script which can report
      or veto access. This can be used to track or regulate what a
      Java applet can do, in case someone happens to browse a web
      site which exploits a Java hole to browse your system or damage

   * You can  hide files from unauthorized access. If someone not
   authorized to access a file tries to open it, they can be set to
   open instead some other file anywhere on the system. Meanwhile,
   Safety generates alarms and can execute site specific commands
   to react to the illegal access before it can happen. This can be
   helpful in gathering evidence of what a saboteur is up to
   without exposing real sensitive files to danger. Normal access
   goes through transparently.

   * You can arrange that opening a file  grants identifiers to the
   process that opens it and that closing it revokes these
   identifiers. Set an interpretive file to do this and set it to
   be openable only by the interpreter and you have a protected
   subsystem capability that works for 4GLs which are interpretive.
   (Safety identifier granting, privilege modification, and base
   priority alteration is protected by a cryptographic
   authenticator preventing forging or duplication.)

   * You can actively prevent covert code ( viruses and worms) from
   running in two ways. First,   Safety can attach a cryptographic
   checksum to a file such that the file will not open if it has
   been tampered with. Second,  Safety can attach a privilege mask
   to a file which will replace all privilege masks for the process
   that opens it. By setting such a mask to minimal privileges, you
   can ensure that an untrusted image will never see a very
   privileged environment, and thus will be unable to perform
   privilege-based intrusions into your system even if run from a
   privileged user's account.

   * You can  control base priority by image. Thus, a particularly
   CPU intensive image can be made to run at lower than normal base
   priority even if it is run interactively.

   * You can run a site-chosen script to further refine selection
   criteria. (Some facilities for doing additional checking while
   an image runs exist also.)

   Safety  allows you to exempt certain images (e.g., disk
   defragmenters) from access checks, and it is possible to put a
   process into a temporary override mode also (leaving a record
   this was done) where this is needed.     Safety  facilities are
   controllable per disk, and impose generally negligible overhead.
   Safety  will work with any VMS file structure using the normal
   driver interfaces. Also,   Safety  marking information resides
   sufficiently in kernel space that it cannot be removed from
   lower access modes, yet it uses a limited amount of memory
   regardless of volume size.

   Best of all, the Safety  protection is provided  within the file
   system  and does not depend on the audit facility. Thus it
   prevents file access or loss   before it happens, and does not
   have to react to it afterwards.      Safety allows all of its
   security provisions to be managed together in a simple
   screen-oriented display in which files, or groups of files, can
   be tagged with the desired security profiles or edited as
   desired.  Safety  protections are in addition to normal VMS file
   protections, which are left completely intact. Therefore, no
   existing security is broken or even altered. Safety  simply adds
   additional checking which finally provides a usable machine
   encoding of "need to know" for the files where it matters.

   The Safety Deletion Protection Subsystem.

   Description: The Safety  Deletion Protection System is designed
   to provide protection against accidental deletion of file types
   chosen by the site, and to allow files to be routed by the
   system to backup media before they are finally removed from the
   system. This is accomplished by an add-in to the VMS file system
   so that security holes are not introduced by the system's

   The user interface is an  UNDELETE command which permits one or
   more files to be restored to their original locations provided
   it is issued within the site-chosen time window after the
   undesired deletion took place. In addition, an   EXPUNGE command
   is provided which allows files to be deleted at once,
   irretrievably, where space for such is required. Provision for
   automatic safe-storing of files prior to final deletion is
   present also in Safety DPS.

   Safety DPS is implemented as a VMS file system add-in which
   functions by intercepting the DELETE operation and allowing the
   file to be deleted to be copied or renamed to a "wastebasket"
   holding area pending final action, and to be disposed of by a
   disposal agent. The supplied agent will allow a site script to
   save the files if this is desired, and then finally deletes any
   files which have been deleted more than some number N seconds
   ago. If the UNDELETE command is given, the file(s) undeleted are
   replaced in their original sites. The supplied system can also
   be configured to rename files to a wastebasket area or to copy
   them directly, for undeletion by systems people only. (These
   options are faster than the site command file option.)

   Safety DPS can be configured to omit certain file types from
   deletion protection (for example, *.LIS* or *.MAP* could be
   omitted), to include only certain files in the protected sets,
   or both. This can reduce the overhead of saving files which are
   likely to be easily recreated, or tailor the system for such
   actions as saving all mail files (by selecting *.MAI for

   In addition, Safety DPS monitors free space on disks, and when a
   file create or extend would cause space exhaustion,   Safety DPS
   runs a site script. By setting this script to perform final
   deletions, Safety DPS can be run in a purely automatic mode in
   which deleted files are saved as long as possible, but never
   less than some minimum period (e.g., 5 or 10 minutes).

   Safety DPS files can be stored in any location accessible to
   VMS. If they are renamed, they must reside on the same disk they
   came from. Otherwise they can be stored in any desired place.

   Safety DPS is installed and configured using a screen oriented
   configuration utility to set it up, and basically runs
   unattended once installed.

   The Safety Storage Migration Subsystem


   Safety has the ability to move files to secondary storage and
   automatically retrieve them when they are accessed. This backing
   can be similar to what HSM systems call "shelving", though it
   can be done in multiple levels, or it can be done in a way which
   permits files moved to secondary storage to be accessed there as
   though the files remained online. This resembles what are called
   "soft links" in Unix systems, in that file opens are
   transparently redirected to a file stored somewhere else
   reachable on the system, and the channel reset to the original
   device on close. A "readonly link" mode acts like a soft link
   for readonly access, and like an unshelve operation where a file
   is opened read/write, should this be desired. Full control over
   this shelving and unshelving is provided.

   This provides a great deal of flexibility in reclaiming space
   when the Safety space monitoring function detects that space is
   needed. Not only can previously deleted files be finally moved
   to backup destinations and deleted, but the system can migrate
   seldom accessed files to nearline storage transparently. The
   site policy can drive this, or utilities provided can be used

   Where it is chosen to run  Safety in a lights-out fashion (with
   Safety reacting to low disk situations by emptying older deleted
   files from the wastebasket and/or file migration to backing
   store), the policy chosen for controlling such setting is
   handled by a full-screen, easily used, tool which sets the
   policy. Should still greater flexibility be needed, the scripts
   used for a number of operations are supplied together with a
   full description of the command line interface of the underlying
   software. This facilitates linking      Safety file management
   functions with other packages should such be desired.

   Safety can be run in a mode where there is essentially no
   overhead at all imposed (just a few instructions added along
   some paths and no disk access) for any files except those which
   need softlinks or possible unshelving. There is no limit to how
   many files may be so marked on a disk. A fullscreen setup script
   allows one to select the   Safety run modes. Even if   Safety is
   forced to examine all files for its markings, the overhead
   imposes no added disk access and costs only a tiny added time
   (typically a percent or two) in open intensive applications. In
   addition, Safety can be turned off or back on at any convenient
   point should this be desired. (This must be done using special
   tools provided for use by those specially authorized to do so.)


  Safety runs on VAX VMS 5.5 or greater or AXP VMS 6.1 or greater.
   The same facilities exist across all systems. HSM must be
   installed on each cluster node of a VMScluster where it is to be
   used but imposes no restrictions on types of disk it works for.
   Safety will work with any file structure used by VMS, so long as
   a disk class device is used to hold it. It is specifically NOT
   limited to use with ODS-2 disks.

   Safety  is brought to you by

   General Cybernetic Enterprises
   Glenn C. Everhart
   101 Long Drive or 156 Clark Farm Road
   Elkton, Md 21921 or Smyrna, Delaware 19977
   302 373 5382 voice
   no fax


Mail for further questions
Authentication whitepaper (spreadsheet and relational DBMS for many systems with full src.)
analylinuxwrk.zipSpreadsheet for Linux terminals with relational DBMS, recent port update with all src and doc AnalyRim for Linux, compiles with Gnu F77 (includes src)
Paper about ideas for a more complete authentication system
Paper abut reasons for fraud and considerations for fixing it
Paper about a way to authenticate in presence of malware

Slight rework of old texto steganography for 64 bit linux. Some issues but basic function works. Encodes info as mad-lib sentences so to automata it looks like plain text.

Method to detect MITM after setup of a Diffie Hellman exchange
Discussion of a brain model, Word format
Safety architecture and features needed for a more modern access control system
